Designed to take advantage of water cooling effect and easy operation. |
| |
|
Low noise level provide maximum productivity and comfortable working |
| |
|
environment. |
| |
|
The cooling efficiency of water is 10% better than Air cooling system (If good |
| |
|
coolant is supplied). |
| |
|
Perfect safe operation is secured by various protection and safety devices |
| |
|
with automatic pre-checking to prevent freezing rupture and / or compressor |
| |
|
overheating. |
| |
|
Designed and structured to facilitate easy maintenance and easy check on |
| |
|
operation. |
|
| |
|
|
| |
|
| |
Model |
Output
Compressor |
Circulation
Pump |
Flow
Rate |
Tank
Volume |
Cooling
Capacity |
Cooling
Volume |
Voltage |
Total
Electricity |
| |
HD-01W |
0.75(1) |
0.25(1/3) |
10/13 |
15 |
2800/3000 |
13 |
1PH 220V |
1 |
| |
HD-02W |
1.5(2) |
0.25(1/3) |
18/20 |
25 |
5600/6000 |
26 |
AC 3PH 220,380V,
440V,460V/50Hz,60Hz |
1.75 |
| |
HD-03W |
2.2(3) |
0.4(1/2) |
25/30 |
65 |
8000/8800 |
40 |
2.6 |
| |
HD-05W |
3.75(5) |
0.4(1/2) |
45/50 |
100 |
14000/15000 |
70 |
4.15 |
| |
HD-07.5W |
5.5(7.5) |
0.75(1) |
60/70 |
130 |
18000/21000 |
100 |
6.25 |
| |
HD-010W |
7.5(10) |
0.75(1) |
85/100 |
150 |
28000/30500 |
130 |
8.25 |
| |
HD-015W |
11.25(15) |
1.5(2) |
120/150 |
240 |
37600/42000 |
190 |
12.75 |
| |
HD-020W |
15(20) |
2.2(3) |
177/200 |
300 |
55400/61000 |
250 |
17.2 |
| |
HD-030W |
22.5(30) |
2.2(3) |
262/300 |
430 |
84100/91000 |
380 |
24.75 |
| |
HD-040W |
30(40) |
3.75(5) |
353/400 |
550 |
116000/120000 |
510 |
36 |
|
| |
-
This specifications is subject to change in case of quality.
|
| |
-
Custom-made order production is possible. |
| |
-
Possible to manufacture special chiller with temperature deviation, ±0.1℃ |
|
|
|
 |
|
|
| |
|
|
|
