Applicable for small space and convenient mobile caster.



Green lamp(DC/24V) is installed for easy check on operation status, Red

    lamp with buzzer alarm at malfunctioning.


Provides accurate adjustment of temperature and minimize temperature

    deviation in the event of decreased productivity or increased defects due to
    high temperature caused by lack of water in cooling tower.



Remarkable cooling system that eliminate completely the uncomfortable working conditions caused by

    humidity and high internal temperature during summer.


Designed to use in case the indoor working conditions are not proper due to heterogeneous properties and

    foreign materials.


Compact internal structure makes it possible to install under any condition.



Maximum cooling effect by centralized supply system of cold water.



  Model

Output
Compressor

Circulation
Pump

Flow
Rate

Tank
Volume

Cooling
Capacity

Voltage

Total
Electricity
  HD-01A 0.75(1)

0.25(1/3)

10/13

 15

2600/2900

1PH 220V

1.1
  HD-02A

1.5(2)

0.25(1/3)

18/20

 25

5400/5600

AC 3PH 220,380V,
440V,460V/50Hz,60Hz

2.15
  HD-03A

2.2(3)

0.4(1/2)

25/30

 65

7500/8000

2.95


HD-05A

3.75(5)

0.4(1/2)

45/50

 100

13000/14000

4.55


HD-07.5A

 5.55(7.5)

0.75(1)

60/70

 130

18000/19800

 7


HD-010A

7.5(10)

0.75(1)

60/70

 150

25200/28000

8.65


HD-015A

11.25(15)

1.5(2)

120/150

 240 30000/38000

13.55


HD-020A

15(20)

2.2(3)

177/200

 300

50400/56000

18.7


HD-030A

22.5(30)

2.2(3)

262/300

 430

75600/84000

 27


HD-040A

30(40)

3.75(5)

353/400

 550

100000/112000

 36


- This specifications is subject to change in case of quality.
  - Custom-made order production is possible.
  - Standard temperature between cold water input and output is △T 5℃
  - Possible to manufacture special chiller with temperature deviation, ±0.1℃
